| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4430.2597 is a 2-pole thermal circuit breaker with a 20A current rating and a voltage rating of 240VAC / 60VDC. It is designed for panel mounting and features rocker actuation.
This circuit breaker offers a conditional short circuit capacity of 1 kA at 240VAC and various Icn ratings depending on the current and voltage conditions. It has a mechanical lifetime of 50,000 switching cycles and overload capabilities specified for AC and DC.
Environmental specifications include an operating temperature range of -10°C to 55°C and a degree of protection of IP40 on the front side. The device also meets specific vibration and shock resistance standards.
Applications for this thermal circuit breaker include power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment.
The circuit breaker is rated for 240 VAC and 60 VDC operation.
The breaker is panel mount.
The operating temperature range is -10°C to 55°C.
The rated current is 20 A.
It is approved under CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077.
Yes, it has a green illumination rated for 20 V.
The mechanical lifetime is 50,000 switching cycles.
