| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4430.2595 is a 2-pole thermal circuit breaker designed for reliable overload protection. It offers a rated current of 10A and can handle up to 240VAC or 60VDC.
This circuit breaker features a thermal tripping mechanism and a rocker actuator for easy operation. It is designed for panel mounting, making it suitable for integration into various industrial appliances, power supplies, and equipment for construction. The device has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -10°C to 55°C.
Key specifications include a conditional short circuit capacity of 1 kA and a short circuit capacity of 300A at 240VAC. The degree of protection is IP40 on the front side, which can be increased to IP54 with a factory-mounted protection cover. It also provides a dielectric strength of 4 kVAC and an insulation resistance greater than 100 MΩ at 500 VDC.
The circuit breaker is rated for 240 VAC and 60 VDC.
The allowable operating temperature is -10 °C to 55 °C.
The device is panel mount.
It has a rocker actuator.
The circuit breaker has IP40 protection, and IP54 with the factory-mounted protection cover.
The mechanical life is 50,000 switching cycles.
The rated current is 10 A.
