The Schurter Inc. 4430.2375 is a thermal circuit breaker featuring a 2-pole configuration and a rocker actuation type. It is designed for panel mounting and offers a current rating of 12A, with a rated voltage of 240VAC and 60VDC.
This circuit breaker provides thermal overload protection with a tripping type that is thermal. It has a mechanical lifetime of 50,000 switching cycles and electrical lifetimes of 50,000 cycles for both AC and DC operations. The operating temperature range is -10°C to 55°C.
Key technical data includes a conditional short circuit capacity of 1 kA and a short circuit capacity Icn of 300A. The degree of protection is IP40 on the front side, and IP54 with a factory-mounted protection cover. It also features a dielectric strength of 4 kVAC and an insulation resistance greater than 100 MΩ at 500 VDC.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment. It meets various approval standards, including VDE, UL, and CCC.
The rated voltage is 240 VAC and 60 VDC.
The rated current range is 0.05 - 20 A.
It has 2 poles.
The allowable operation temperature is -10 °C to 55 °C.
It is RoHS3 Compliant.
The MSL is 1 Unlimited.
It is REACH Unaffected.
