| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Industrial Grade | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4430.2051 is a thermal circuit breaker featuring a 2-pole configuration and rocker actuation. It is rated for 240 VAC and 60 VDC, with a current range of 0.05 to 20 A.
This circuit breaker has a mechanical lifetime of 50,000 switching cycles and an AC overload rating of a minimum of 40 trips at 6 times the rated current. It operates within a temperature range of -10 °C to 55 °C.
Designed for panel mounting, the 4430.2051 includes approvals from CSA, EN, GB, IEC, and UL. It also features green illumination with a nominal voltage of 220V.
Applications for this thermal circuit breaker include power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment.
240 VAC and 60 VDC.
-10 °C to 55 °C.
2 poles.
Conditional short circuit capacity Inc is 1 kA at 240 VAC; Icn is 300A for In ≥ 3A at 240 VAC.
Panel mount.
Yes, green illumination with nominal voltage 220V.
CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077.
