| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4430.1536 is a 2-pole thermal circuit breaker with a panel mount design. It offers a rated voltage of 240 VAC and 60 VDC, with a current rating range of 0.05 to 20 A AC. The breaker type is thermal, and it features a rocker actuation.
Key technical specifications include a conditional short circuit capacity of 1 kA and a short circuit capacity Icn of up to 300A. The degree of protection on the front side is IP40, which can be increased to IP54 with a factory-mounted protection cover. It has a dielectric strength of 4 kVAC and an insulation resistance greater than 100 MΩ at 500 VDC.
Mechanical specifications include a lifetime of 50,000 switching cycles for both mechanical and AC/DC operation. The operating temperature range is -10 °C to 55 °C, with a similar storage temperature range. Vibration resistance is tested to IEC 60068-2-6, and shock resistance to IEC 60068-2-27.
This circuit breaker is suitable for applications such as power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment. It is designed for reliable thermal overload protection with a positively trip-free release mechanism.
The rated current is 13A.
It is rated for 240VAC and 60VDC.
It uses a rocker actuator.
The allowable operating temperature is -10°C to 55°C.
The front side is rated IP40, and with a factory-mounted cover it is IP54.
It is a 2-pole circuit breaker.
