| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
This Schurter Inc. 4430.1296 is a thermal circuit breaker with a 2-pole configuration, suitable for various applications requiring reliable overload protection.
Key electrical specifications include a rated voltage of 240 VAC and 60 VDC, with a rated current range of 0.05 to 20 A. The breaker offers a conditional short circuit capacity of 1 kA AC and a short circuit capacity of up to 300A AC. It has a mechanical lifetime of 50,000 switching cycles and an overload capability of a minimum of 40 trips at 6 times the rated current for AC.
The device is designed for panel mounting and features a rocker actuation type. Environmental specifications include a degree of protection of IP40 on the front side and an operating temperature range of -10 °C to 55 °C. The insulation resistance is greater than 100 MΩ at 500 VDC, and it has a dielectric strength of 4 kVAC.
Approvals include CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077, indicating compliance with various international safety standards.
240VAC and 60VDC.
-10°C to +55°C.
Thermal tripping.
2 poles.
Panel mount.
16A.
CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077.
