| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4430.107 is a thermal circuit breaker featuring a 2-pole configuration and a rocker actuation type. It is designed for panel mounting and has a current rating of 20A, with a rated voltage of 240 VAC and 60 VDC.
This circuit breaker provides thermal overload protection and has a conditional short circuit capacity of 1 kA at 240 VAC. It meets various approval standards including CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077. The operating temperature range is -10 °C to 55 °C.
Applications for this component include power tools, industrial appliances, power supplies, and equipment for construction and cleaning. It features a mechanical lifetime of 50,000 switching cycles and overload capabilities specified for AC and DC circuits.
The degree of protection for the front side is IP40, which can be increased to IP54 with a factory-mounted protection cover. The insulation resistance is greater than 100 MΩ at 500 VDC, and it has a dielectric strength of 4 kVAC.
The rated voltage is 240 VAC and 60 VDC.
The allowable operating temperature is -10°C to 55°C.
The rated current is 20A.
It uses a rocker actuator.
It has 2 poles.
The degree of protection is IP40, and IP54 with the factory mounted protection cover.
It is approved to CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077.
