The Schurter Inc. 4430.1038 is a thermal circuit breaker designed for reliable overcurrent protection in industrial and commercial applications. It features a 2-pole configuration with rocker actuation and panel mount installation, rated for 10A continuous current at 240VAC or 60VDC.
This breaker offers a dielectric strength of 4 kVAC and insulation resistance greater than 100 MΩ. It is rated for 50,000 mechanical and electrical switching cycles, with overload capability of at least 40 trips at 6x rated current (AC) or 4x rated current (DC). The operating temperature range is -10°C to 55°C, and it meets IP40 protection (IP54 with optional cover).
It is suitable for equipment requiring branch circuit protection and complies with multiple international standards such as IEC 60934, UL1077, and CSA C22.2 No 235. The panel mount design and compact size make it easy to integrate into control panels, power supplies, and other electrical enclosures.
The 4430.1038 is rated for 240VAC and 60VDC operation.
The allowable operating temperature range is -10°C to 55°C.
The breaker has a rated current of 10A, with an AC current range of 0.05 to 20A.
It uses a thermal tripping mechanism.
The breaker is designed for panel mount installation.
