The Schurter Inc. 4430.0988 is a thermal circuit breaker featuring a 2-pole configuration and rocker actuation, suitable for panel mounting. It is rated for 240 VAC and 60 VDC, with a current range of 0.05 to 20 A AC.
This circuit breaker provides thermal overload protection with a conditional short circuit capacity of 1 kA at 240 VAC. It has a dielectric strength of 4 kVAC and an insulation resistance greater than 100 MΩ at 500 VDC. The mechanical lifetime is rated for 50,000 switching cycles.
Designed for industrial applications, the 4430.0988 operates within a temperature range of -10 °C to 55 °C. It meets IP40 degree of protection on the front side. Approvals include VDE, UL, and CCC.
Key specifications include a 20A rated current, 240V AC voltage rating, and 2 poles. The tripping type is thermal, and the actuation type is rocker. It is designed for robust performance in demanding environments.
The rated voltage is 240 VAC and 60 VDC.
The rated current range is 0.05 to 20 A AC.
This circuit breaker has 2 poles.
The allowable operation temperature is -10 °C to 55 °C.
It uses rocker actuation.
The mounting type is panel mount.
