This Schurter Inc. 4430.0561 is a thermal circuit breaker featuring a 2-pole configuration and rocker actuation. It is designed for panel mounting and provides a rated current of 3.5A with a voltage rating of 240VAC.
The device offers thermal overload protection with a positively trip-free release mechanism. Key electrical specifications include a rated voltage of 240 VAC and 60 VDC, with a rated current range of 0.05 - 20 A. The conditional short circuit capacity is 1 kA at AC 240V, and the short circuit capacity Icn can reach up to 300A.
Environmental and mechanical specifications include a degree of protection of IP40, dielectric strength of 4 kVAC, and insulation resistance greater than 100 MΩ at 500 VDC. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -10 °C to 55 °C. The circuit breaker also exhibits resistance to vibration and shock according to IEC standards.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, and equipment for construction and cleaning. It is suitable for industrial environments and meets various approval standards.
The rated voltage is 240 VAC and 60 VDC.
The current rating is 3.5A.
This circuit breaker has 2 poles.
It features rocker actuation.
The allowable operating temperature range is -10 °C to 55 °C.
