| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating |
This Schurter Inc. 4430.0523 is a thermal circuit breaker with a 2-pole configuration, suitable for various industrial applications. It offers a rated voltage of 240 VAC and 60 VDC, with a current rating range of 0.05 to 20 A, and specifically rated at 11A for this model.
The breaker features a rocker actuation and a panel mount design for easy integration into equipment. It provides a conditional short circuit capacity of 1 kA at 240 VAC and a short circuit capacity of 300A at 240 VAC. The device is designed for a mechanical lifetime of 50,000 switching cycles and operates within a temperature range of -10 °C to 55 °C.
Key electrical specifications include a dielectric strength of 4 kVAC and an insulation resistance greater than 100 MΩ at 500 VDC. The degree of protection for the front side is IP40. Applications for this type of circuit breaker include power tools, industrial appliances, power supplies, and equipment for construction and cleaning.
Approvals include VDE, UL, and CCC, indicating compliance with relevant safety standards. The unit has a weight ranging from 30 g to 50 g.
The rated voltage is 240 VAC and 60 VDC.
The current rating is 11A.
It has 2 poles.
It uses rocker actuation.
The allowable operation temperature is -10 °C to 55 °C.
The degree of protection for the front side is IP40.
