The Schurter Inc. 4430.0429 is a thermal circuit breaker designed for equipment protection. It offers a 7A current rating and is suitable for AC applications up to 240 VAC and DC applications up to 60 VDC.
This 2-pole breaker features a rocker actuation type and a panel mount design for easy integration into control panels. It provides thermal overload protection with a conditional short circuit capacity of 1 kA at 240 VAC. The operating temperature range is -10 °C to 55 °C.
Key specifications include a mechanical lifetime of 50,000 switching cycles and an insulation resistance of >100 MΩ at 500 VDC. The degree of protection is IP40 on the front side, increasing to IP54 with a factory-mounted protection cover.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, and equipment for construction and cleaning.
240VAC and 60VDC.
7A.
-10°C to 55°C.
Thermal.
Rocker.
IP40 front side, IP54 with protection cover.
50,000 switching cycles.
