| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4410.017 is a thermal circuit breaker designed for reliable protection in various applications. This 1-pole device features a compact design with quick connect terminals and a push-to-reset actuator, suitable for panel mounting.
With a rated voltage of 240V AC and 28V DC, and a current rating of 600mA, it offers protection against overcurrent conditions. The circuit breaker is built to withstand demanding environments, evidenced by its IP40 degree of protection and robust mechanical specifications including vibration and shock resistance.
Key technical data includes a conditional short circuit capacity of 1 kA and a typical endurance of 5000 switching cycles. The operating temperature range is -5°C to 60°C, making it suitable for a wide array of industrial and household applications such as power supplies, uninterruptible power supplies, and power tools.
The 4410.017 is rated for 240VAC and 28VDC.
The allowable operating temperature range is -5°C to 60°C.
The 4410.017 is a panel mount circuit breaker.
It is approved to CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077.
The front side is rated IP40 according to IEC 60529.
