| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4410.0151 is a thermal circuit breaker designed for equipment protection. This 1-pole breaker features a threaded neck type with quick connect terminals (6.3 x 0.8 mm) and a panel mount capability.
Key electrical specifications include a rated AC voltage of 240 VAC and a rated DC voltage of 28 VDC. The rated current range is from 0.05 to 15/16 A. It offers a conditional short circuit capacity of 1 kA at 240 VAC and a short circuit capacity Icn of 8 x In for In < 7 A/240 VAC, and 200 A for In ≥ 7 A/240 VAC. For AC/DC 28 V, the short circuit capacity is 400 A.
This circuit breaker operates within a temperature range of -5 °C to 60 °C. It is designed with a positively trip-free release mechanism and has a weight of approximately 10 g. The degree of protection on the front side is IP40.
Approvals include CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077, indicating compliance with various international safety standards. Applications include power supplies, uninterruptible power supplies, power tools, and household appliances.
240 VAC and 28 VDC.
15A.
-5°C to 60°C.
Panel mount.
CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077.
Thermal.
Push to reset.
