The Schurter Inc. 4410.0004 is a thermal circuit breaker with a threaded neck type and quick connect terminals. It features a compact design and positively trip-free release.
This circuit breaker is rated for 240 VAC and 28 VDC, with a rated current range of 0.05 to 15/16 A. It has a conditional short circuit capacity of 1 kA at 240 VAC and a short circuit capacity of 200 A at In ≥ 7 A/240 VAC. The device is designed for overload protection with a minimum of 40 trips at 6 x Ir (IEC) and 50 trips at 1.5 x Ir (UL/CSA).
Environmental specifications include an operating temperature range of -5 °C to 60 °C and a degree of protection of IP40 on the front side. It also meets vibration resistance standards of ± 1.5 mm @ 10 - 60 Hz and 10 G @ 60 - 500 Hz, and shock resistance of 100 G / 6 ms.
Applications for this circuit breaker include power supplies, uninterruptible power supplies, power tools, and household appliances. It is designed according to IEC 60934 standards.
Rated 240VAC and 28VDC.
Panel mount.
-5°C to 60°C.
1 kA at 240VAC; 200A for In≥7A or 400A at 28VDC.
>1.5 kV at 50 Hz and >2.5 kV impulse.
5000 switching cycles typical, 50 minimum.
