The Schurter Inc. 4404.0102 is a single-pole thermal circuit breaker designed for reliable protection in various applications. It features THT terminals for convenient PCB mounting and a push-to-reset actuator.
This circuit breaker has a rated current of 10A and a voltage rating of 240VAC, with a DC rating of 48/32VDC. It offers a conditional short circuit capacity of 2 kA according to IEC 60934 and UL/CSA standards. The device is designed for a minimum of 50 switching cycles at 200% Ir and cos φ 0.6, with typical endurance of 2500 cycles for 3-8A and 6000 cycles for 10-15A at 150% Ir and cos φ 0.9.
With a degree of protection of IP40 on the front side, it is suitable for industrial environments. The operating temperature range varies slightly with current rating, from -5°C to 60°C for most ratings. It meets product standards including IEC 60934, UL 1077, CSA C22.2 No. 235, and GB 17701, and is suitable for applications compliant with IEC/UL 62368-1.
The circuit breaker is RoHS3 compliant and designed for wave soldering with a solderability rating of 245°C for 3 seconds and resistance to soldering heat of 260°C for 10 seconds.
The rated voltage is 240 VAC and 48/32 VDC.
The rated current is between 3A and 15A.
The operating temperature range is -5°C to 60°C for 3A and 5-15A ratings, and -5°C to 50°C for the 4A rating.
Yes, the product is RoHS3 Compliant.
It is designed according to IEC 60934, UL 1077, CSA C22.2 No. 235, and GB 17701.
The degree of protection on the front side is IP40.
