| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
523 pcs
|
523 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Operating Temperature | |
| Operating Voltage | |
| Quiescent Current |
The 4053 is a versatile multiplexer/demultiplexer IC from Heyco Products Corporation, designed for switching both digital and analog signals. It belongs to the standard logic 40xx family.
Key electrical specifications include an operating voltage range of 3-15V (Vdd-GND or Vdd-Vee) with a maximum rating of 18V. The typical on-resistance is 125 ohms, and the quiescent current is less than 0.2mA. The device operates reliably within a temperature range of -40°C to +85°C.
This component features 6 communication channels, grouped into three pairs, controlled by four signals: A, B, C, and INH. Signals A, B, and C determine which channels are active, while INH provides overall enable/disable functionality (active low). The 4053 can be used with both single-ended and differential power supplies. For digital signal switching, the Vee pin can be connected to the GND.
The 4053 is available in two common package types: DIP-16 and SO-16, suitable for through-hole mounting.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage range is 3V to 15V, with a maximum of 18V.
The 4053 is available in DIP-16 and SO-16 packages.
-40°C to +85°C.
Less than 0.2mA.
125 ohm.
