| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The N2Power XL100 Series 400575-01-5 is a high-efficiency AC-DC power supply designed for demanding applications. This open-frame unit delivers up to 100W of power with a single 12V output, achieving efficiencies as high as 92% and reducing energy losses.
It features a wide input voltage range of 85 to 264 VAC and also supports DC-DC input from 120 to 370 VDC. The power supply operates with convection cooling, providing full power without the need for a fan. Key electrical features include active power factor correction, a built-in EMI filter, and adjustable output voltage (±10%).
With dimensions of 3.00" L x 2.00" W x 1.16" H (76.2mm x 50.8mm x 29.5mm), it is designed for chassis mounting. The unit offers 3000 VAC input-to-output reinforced insulation and protection class I or II. Its low leakage current (≤ 300 uA) and operating altitude of up to 5000 meters make it suitable for diverse environments.
Applications include personal computers, wireless networking, measurement equipment, telecom/datacom, and industrial control systems. It is certified by CB, CE, cURus, FCC, and UKCA, adhering to standards like 60950-1 and 62368-1.
The N2Power 400575-01-5 provides a power output of 100W.
This AC-DC converter has a wide input voltage range of 85 to 264 VAC.
The 400575-01-5 has a single output voltage of 12V.
The N2Power 400575-01-5 achieves a maximum efficiency of 92%.
The dimensions are 76.2mm (3.00") L x 50.8mm (2.00") W x 29.5mm (1.16") H.
The operating temperature range is -40°C to 85°C.
The 400575-01-5 is designed for chassis mount.
