| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
11,727 pcs
|
11727 pcs | On Request | 1 | On Request | On Request | 1902+ | On Request | On Request | |
|
1,859 pcs
|
1859 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The TE Connectivity 4-794618-2 is a 12-position, 2-row, 3.00mm pitch header connector designed for board-to-cable/wire applications. It features a right angle through hole mounting configuration, allowing for space-efficient PCB layouts. The 4-wall shrouding protects the male pins, and the integrated locking ramp ensures a secure connection with compatible receptacles.
This header is rated for 250V AC/DC, with current capacity varying by wire gauge. The contacts are made of brass with a tin finish (100µin thickness), providing reliable conductivity. The insulation material is black polyamide (nylon) with a UL94 V-0 flammability rating, and the operating temperature range is -40°C to 105°C.
Designed for durability, the header features a fastening type of locking ramp and includes a board lock feature for additional PCB retention. The contact shape is square, and the termination method is solder. This component is suitable for a variety of industrial, automotive, and consumer electronics applications requiring a robust rectangular connection.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.95 | $2.95 |
| 10+ | $2.51 | $2.51 |
| 169+ | $2.05 | $2.05 |
| 507+ | $1.90 | $1.90 |
| 1,014+ | $1.81 | $1.81 |
| 5,070+ | $1.62 | $1.62 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
12 positions, all loaded.
3.00mm (0.118 inches).
The current rating varies depending on the wire gauge used.
250V.
Through hole, right angle.
Tin, with a thickness of 100µin (2.54µm).
-40°C to 105°C.
