| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Depth | |
| For Use With | |
| Height | |
| Width |
This Siemens 3VA9137-0HA10 is a motor operator accessory, part of the SENTRON product line. It is specifically designed as an accessory for the 3VA5 125 circuit breaker series.
The general technical data indicates a rated control supply voltage of 24V DC and a rated operational power of 250 VA. The mechanical design features dimensions of 70 mm in height, 76.2 mm in width, and 103 mm in depth, with a net weight of 578 g. It supports conductor cross-sections ranging from 1.5 mm² to 2.5 mm² for solid, finely stranded, and stranded conductors.
Environmentally, the motor operator is suitable for operation between -25°C and 70°C, with storage temperatures ranging from -40°C to +80°C. Mechanical connections require a tightening torque between 0.36 N·m and 0.44 N·m, with a stripped length of 7 mm for connections.
Further information and documentation, including catalogs, brochures, and technical support, can be found on the Siemens industry website.
The rated control supply voltage is 24 V DC.
The rated operational power is 250 VA.
The dimensions are 70 mm in height, 76.2 mm in width, and 103 mm in depth.
The ambient temperature during operation ranges from -25 °C to 70 °C.
It supports solid, finely stranded, and stranded conductors with cross-sections from 1.5 mm² to 2.5 mm².
The minimum tightening torque is 0.36 N·m and the maximum is 0.44 N·m.
