The Siemens SENTRON 3VA5 Molded Case Circuit Breaker is a robust 3-pole device designed for industrial applications requiring reliable line protection. It features a 70A current rating and a significant breaking capacity of 65kA, ensuring safety under demanding conditions.
This circuit breaker operates at a rated AC voltage of 690V and a rated DC voltage of 750V. It is equipped with overload and short circuit protection, utilizing ATAM and TM240 tripping mechanisms. The fixed mounting type ensures a secure installation.
Constructed for durability, the 3VA5 series offers a protection class of IP40, safeguarding against dust and moisture ingress. It boasts a mechanical service life of up to 20,000 operating cycles, providing long-term performance. The breaker's dimensions are 105mm in width, 185mm in height, and 83mm in depth.
Ideal for applications requiring superior protection in complex environments, this circuit breaker is a dependable choice for engineers. Its design supports various industrial uses, offering consistent performance.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 70A.
The breaking capacity is 65kA.
The rated AC voltage is 690V ac.
The rated DC voltage is 750V dc.
It has 3 poles.
It uses fixed mounting.
The protection class is IP40.
