This Siemens 3VA5220-5ED32-0AA0 is a 3-pole molded-case circuit breaker from the 3VA5 UL frame 250 series. It is designed for system protection and features a TM210 thermal-magnetic overcurrent release with LI protection function. The breaker has a rated operational voltage of 690V AC and a current rating of 200A at 40°C, with derated values at higher temperatures.
With a breaking capacity of 35kA at 480V according to UL 489, and 7kA at 690V according to IEC 60947, this circuit breaker offers robust protection. It has a mechanical service life of 20,000 cycles and electrical endurance ratings suitable for demanding applications. The dimensions are 185mm in height, 105mm in width, and 83mm in depth, with a net weight of 2.192 kg. It is designed for DIN rail mounting.
The breaker is HACR Type compliant, suitable for Heating, Air Conditioning, and Refrigeration circuits. It operates with a fixed short-circuit protection setting of 10 x In. The product is RoHS3 Compliant, MSL 1 Unlimited, and REACH Unaffected, though these compliance statuses are unverified.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operational current rating is 200A at 40°C.
The operating voltage at AC is rated for 690 V.
The breaking capacity at 480V is 35 kA.
This is a 3-pole circuit breaker.
The typical mechanical service life is 20,000 switching cycles.
The dimensions are 185 mm in height, 105 mm in width, and 83 mm in depth.
