The Siemens 3VA5215-6EC61-0AA0 is a 2-pole molded-case circuit breaker from the SENTRON series, designed for system protection applications. It operates with a maximum rated operational voltage of 690V AC and 500V DC, and has an insulation voltage of 800V.
This circuit breaker has a permanent rated current of 150A, with an adjustable overload protection (Ir) set at 150A and fixed short-circuit protection (Ii) ranging from 750A to 1500A. It offers a breaking capacity of 100 kA at 240V and 65 kA at 480V according to UL 489 standards.
Designed for DIN rail mounting, the 3VA5215-6EC61-0AA0 has a mechanical service life of 20,000 switching cycles and an electrical endurance of 8,000 cycles at 380/415V. Its dimensions are 185mm in height, 105mm in width, and 83mm in depth.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum rated operational voltage is 690 V AC.
The insulation voltage is 800 V.
The mechanical service life is 20,000 switching cycles.
It mounts on a DIN rail.
The breaking capacity at 240 V is 100 kA.
