This Siemens 3VA5112-5ED16-0AA0 is a 1-pole molded-case circuit breaker from the 3VA5 series, designed for system protection applications. It operates with a rated voltage of 415V AC and offers a significant breaking capacity of 35kA at 277V according to UL 489 standards, and 36kA at 240V according to IEC 60947.
The circuit breaker has an operational current rating of 125A at 40°C, with derated values at higher temperatures. It features a TM210 overcurrent release with LI protection function. The device is built for a mechanical service life of 20,000 cycles and electrical endurance of 8,000 cycles at 380/415V.
Designed for easy installation, this breaker is suitable for DIN rail mounting. It has an insulation voltage rating of 500V and a maximum operational voltage of 125V DC. The power loss is rated at a maximum of 10.03W.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The rated operating voltage at AC is 415 V.
The breaking capacity at 277V is 35 kA.
This circuit breaker has 1 pole.
The operational current is 125A at 40°C.
This circuit breaker supports DIN Rail mounting.
