| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Country of Origin | |
| Current Rating (Amps) | |
| Failure Rate | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Rated Current | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating |
This Altech Corporation 3G08UM is a three-pole circuit breaker designed for reliable circuit protection. It operates with a thermal magnetic trip mechanism and features a G trip characteristic, suitable for various industrial applications.
The breaker has a rated current of 0.8A and a voltage rating of 480V. It is designed for DIN rail mounting, facilitating easy installation in control panels and enclosures. The unit offers a short circuit withstand rating of 10kA (UL/CSA) and an interrupting capacity of 10kA (VDE).
Environmental specifications include a degree of protection of IP20 and an operating temperature range of -25°C to 55°C. The vibration resistance is rated at over 15g according to DIN EN 60069-2-59. Terminal torque specifications are provided for secure connections, with acceptable terminal sizes ranging from 18-3 AWG on the top and 18-2 AWG on the bottom.
Compliance includes UL and SA approvals. The product is manufactured in Germany (DE).
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The rated current is 0.8A.
The voltage rating is 480V.
It has three poles.
It uses a thermal magnetic trip mechanism with a G trip characteristic.
The operating temperature range is -25°C to 55°C.
The degree of protection is IP20.
The approval agencies are CSA and UL508.
