| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Ambient Temperature | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating |
This Altech Corporation 3CU32M is a thermal magnetic circuit breaker designed for reliable circuit protection. It features a 3-pole configuration, a current rating of 32A, and a voltage rating of 277V.
The breaker is equipped with a lever actuator for easy operation and is designed for DIN rail mounting, making it suitable for industrial and control panel applications. It offers an interrupting capacity of 10kA and has undergone UL508 certification.
Environmental specifications include a calibration temperature of 40°C, a storage temperature range of -25°C to 75°C, and an IP20 terminal protection rating. The breaker is built for durability with a mechanical life of 10,000 switching cycles and an electrical life of 6,000 switching cycles.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 32A.
The voltage rating is 277V.
The 3CU32M circuit breaker has 3 poles.
It is a thermal magnetic circuit breaker.
It is designed for DIN rail mounting.
The interrupting capacity is 10kA.
The calibration temperature is 40°C (104°F).
