| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
55 pcs
|
55 pcs | On Request | 1 | On Request | On Request | On Request | On Request | 2026-02-16 21:33:16 |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Type | |
| Country of Origin | |
| Current Rating | |
| Dielectric Withstanding Voltage | |
| Insulation Resistance | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Hole Diameter | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature Range | |
| Packaging Type | |
| Pitch | |
| Rated Voltage | |
| Shell Plating | |
| Tail Type | |
| Termination | |
| Termination Style |
The Mill-Max 380-10-105-10-003000 is a machined pin header designed for reliable interconnect applications. It features 5 positions in a single row with a standard 2.54mm (0.100") pitch. The connector uses a solder cup termination style, allowing for easy wire attachment, and is configured for through hole mounting.
The header is constructed with a high temperature thermoplastic insulator and brass alloy contacts. The contacts are finished with 10 microinches of gold over 100 microinches of nickel, providing excellent conductivity and corrosion resistance. The shell plating is similarly specified as 10 microinches gold over 100 microinches nickel.
Electrical ratings include a rated voltage of 100 VRMS / 150 VDC, minimum insulation resistance of 10,000 MΩ, and a minimum dielectric withstanding voltage of 1,000 VRMS. The current rating is application specific. The operating temperature range spans from -55°C to +125°C. The component is RoHS3 compliant, has an MSL of 1 (Unlimited), and is REACH Unaffected.
| Qty | Low | High |
|---|---|---|
| 1+ | $17.50 | $17.50 |
| 40+ | $13.48 | $13.48 |
| 120+ | $12.48 | $12.48 |
| 520+ | $11.25 | $11.25 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
It has 5 positions in a single row.
Through hole mount with solder cup termination.
Rated voltage is 100 VRMS / 150 VDC.
-55°C to +125°C.
