| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
78 pcs
|
78 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
40 pcs
|
40 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Failure Rate | |
| Features | |
| Mounting Type | |
| Must Operate Voltage | |
| Must Release Voltage | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Switching Voltage | |
| Termination Style |
This Finder relay, part number 38.51.7.024.0050, is a general purpose electromechanical relay with a Single Pole Double Throw (SPDT) contact form. It is rated for a contact current of 6A and a switching voltage of up to 400VAC. The relay operates on a 24VDC coil voltage, with a coil current of 10.4 mA. It features a non-latching coil type and includes a socket. The operate time is 5 ms and the release time is 6 ms. The operating temperature range is from -40°C to 70°C. Mounting is achieved via a 35mm DIN rail, and it utilizes screw terminals for connection. The contact material is Silver Nickel (AgNi). This relay is suitable for various industrial control applications.
Common features of the 38 series include integral coil indication and protection circuits, and instant ejection of the relay via a plastic retaining clip. The 38.51/38.61 sub-series, to which this part belongs, is 6.2 mm wide and features 1 CO (6A/250VAC) contacts. This specific model, 38.51.7.024.0050, is designed for 24VDC operation and screw terminal connections.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The contact form is SPDT (1 Form C).
The contact rating is 6A.
The coil voltage is 24VDC.
The operating temperature range is -40°C to 70°C.
It is designed for DIN rail mounting.
It uses screw terminals.
The maximum switching voltage is 400VAC.
