This E-T-A 3600-P10-SI-8A is a single-pole thermal magnetic circuit breaker, part of the 3600 Series. It is designed for panel mounting and features a push-to-reset actuator.
Key electrical specifications include a current rating of 8A and a voltage rating of 250V AC, with a DC voltage rating of 65V. The breaker offers an interrupting capacity of 400A (Icn) and 1000A (UL 1077). It is built with a thermal magnetic tripping mechanism and has a typical operational life of 5,000 cycles.
The operating temperature range is from -30°C to +60°C. The device meets IP40 protection for the operating area. Mechanical specifications include a width of 11.5mm, height of 50mm, and depth of 72mm, with a mass of approximately 45g. It utilizes 6.3-0.8mm blade terminals for connection.
Typical applications for this circuit breaker include process control systems, instrumentation, communications systems, and rail vehicles. It is approved by CSA, IEC, and UL standards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 8A.
The AC voltage rating is 250V.
The DC voltage rating is 65V.
It has 1 pole.
It uses a thermal magnetic tripping mechanism.
The operating temperature range is -30°C to +60°C.
Typical applications include process control systems, instrumentation, communications systems, and rail vehicles.
