| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Plating Underplating | |
| Current Rating | |
| Features | |
| Flammability Rating | |
| Insulation Material | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Temperature Rating | |
| Termination | |
| Termination Style | |
| Wire Accommodation | |
| Withstanding Voltage |
The 3M 3572-1001 is a 14 position IDC plug connector from the 3000 Series D Ribbon Wiremount Plug family. It features a free hanging (in-line) mounting style with IDC termination for 26-28 AWG solid or stranded wire. The connector has a gray glass filled polyester (PBT) insulation housing rated UL 94V-0, and copper alloy contacts with 30 μ″ gold plating over 100 μ″ nickel underplating.
Electrical ratings include 1A current per contact, insulation resistance greater than 1 × 10⁹ Ω at 500 VDC, and withstanding voltage of 1000 Vrms at sea level. The operating temperature range is -55°C to +105°C. A bail lock feature is included for secure mating.
This connector is designed for applications requiring reliable wire-to-board connections in a compact, low-profile package. It is RoHS compliant.
The 3572-1001 has 14 positions arranged in 2 rows.
The current rating is 1 A per contact.
It accepts 26 and 28 AWG solid or stranded wire.
The operating temperature range is -55°C to +105°C.
Yes, the datasheet states it is RoHS compliant.
The mounting type is free hanging (in-line).
