| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Body Material | |
| Current Rating | |
| Current Rating (Amps) | |
| Ingress Protection | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating |
This OptiFuse 351080 is a heavy duty, high amp, waterproof circuit breaker designed for demanding applications. It offers an 80A current rating and a 48VDC voltage rating, suitable for various power distribution needs.
The circuit breaker features an automatic reset mechanism, ensuring continuous operation after a fault. It is built with a thermoset plastic body (UL94V-0) and nickel-plated terminals for durability. The device is IP67 rated for ingress protection, making it suitable for harsh environments.
Compliance with SAE J553 and ABYC-E11 standards, along with SAE J1171 ignition protection, highlights its suitability for automotive and marine applications. The operating temperature range is -32°C to 82°C (-25°F to 180°F).
Mounting is available as surface mount or chassis mount, with specified torque limits for secure installation. The interrupting rating is 3000A @ 30VDC for models up to 150A.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The OptiFuse 351080 circuit breaker has a voltage rating of 48VDC for models up to 200A and 14VDC for models from 250A to 300A.
The OptiFuse 351080 circuit breaker has a current rating of 80A.
The OptiFuse 351080 circuit breaker features an automatic reset type.
The operating temperature range for this circuit breaker is -32°C to 82°C (-25°F to 180°F).
The OptiFuse 351080 circuit breaker can be mounted via surface mount or chassis mount.
This circuit breaker has an IP67 ingress protection rating.
Yes, this circuit breaker meets SAE J1171 ignition protection standards.
