| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
94 pcs
|
94 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Pitch | |
| Cable Termination | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Current Rating | |
| Features | |
| Halogen Free | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature Range | |
| Row Spacing | |
| Termination Style | |
| Wire Gauge | |
| Withstanding Voltage |
The 3M 3434-0000T is an IDC (Insulation Displacement Connector) from the 3400 Series, designed for direct board-to-cable connections. It accommodates 26-28 AWG stranded or solid wire and features 26 positions arranged in a 4-row staggered grid with 0.100" (2.54mm) row spacing and 0.050" (1.27mm) cable pitch.
Electrical ratings include a 1A nominal current, insulation resistance greater than 1×10⁹ Ω at 500 VDC, and a withstanding voltage of 1,000 VRMS at sea level. The operating temperature range spans -55°C to +105°C, making it suitable for a variety of environments.
The connector uses a through hole mounting style with a feed through feature and IDC termination. The housing is made of gray glass-filled polyester (PBT) with a UL 94V-0 flammability rating. Contacts are copper alloy with a tin-lead finish (200µin) over nickel underplating.
This part is commonly used in applications requiring reliable, mass-terminated ribbon cable connections to printed circuit boards. Its low profile and standard staggered grid layout facilitate dense packaging in electronic assemblies.
26 positions.
0.050" (1.27mm).
1 A.
1,000 VRMS at sea level.
Through hole.
0.100" (2.54mm).
Tin-Lead, 200.0µin (5.08µm).
