| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
750 pcs
|
750 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| MSL (Moisture Sensitivity Level) | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The 3M 3433-5002 is a 50-position, 2-row, right angle shrouded header designed for board-to-board or cable applications. It features a 2.54mm pitch and through hole mounting, with a 4-wall shrouded housing that includes a keying slot and mounting flange for secure mating. The insulation is made of black Polycyclohexylenedimethylene Terephthalate (PCT) and polyester, glass filled, with a UL94 V-0 flammability rating.
The contacts are copper alloy with a tin-lead finish, rated for 1.75A continuous current. The operating temperature range is -55°C to 105°C. The header has a contact length of 2.84mm and an insulation height of 8.64mm. Row spacing is also 2.54mm.
This connector is suitable for a variety of industrial and commercial applications requiring a reliable, polarized connection. The right angle orientation allows for low-profile board-to-board connections or cable interfaces.
50 positions.
2.54mm (0.100").
1.75A.
Through hole, right angle.
-55°C to 105°C.
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled.
Tin-Lead.
