The 3M 3428-L302 is a 20-position, 2-row, 2.54mm pitch, right angle, shrouded header designed for board-to-board or cable applications. It features a 4-wall shrouding with keying slot and mounting flange for secure alignment and polarization. The insulator is made of black PCT/glass filled polyester with a UL94 V-0 flammability rating, suitable for a wide operating temperature range of -55°C to 105°C.
Contacts are made of copper alloy with a tin-lead finish (0.76µm thickness) and have a square shape and male pin type. The current rating is 1A. The fastening mechanism includes latch lock/eject hooks for reliable mating. Termination is through solder, and the mounting type is through hole, right angle.
This header is suitable for various industrial, test, and measurement applications where a compact, right-angle connection is required. The shrouded design protects pins and ensures proper mating orientation. The header is stackable, allowing multiple connectors to be used in a stacked configuration.
| Qty | Low | High |
|---|---|---|
| 100+ | $22.25 | $22.25 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
20 positions in 2 rows, all positions loaded.
2.54mm (0.100") pitch.
1A.
Through Hole, Right Angle.
-55°C to 105°C.
Tin-Lead with 0.76µm thickness.
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled, UL94 V-0 rated.
