The 3M 3428-6302 is a 20-position, dual-row shrouded header male pin connector designed for board-to-board or cable applications. It uses a through-hole mounting termination with 2.54mm pitch and row spacing, and features latch lock/eject hooks for secure mating. The insulation is black glass-filled PBT/polyester with UL94 V-0 flammability rating, and includes keying slot and mounting flange features. Contacts are made of copper alloy with a square shape, tin-lead finish (30.0µin thick), and the component is rated for 1A continuous current. The operating temperature range is -55°C to 105°C. Overall contact length is 16.56mm with a mated pin length of 2.84mm.
It has 20 positions, all loaded.
The pitch is 2.54mm (0.100").
The current rating is 1A.
It is a through-hole mounting header.
The operating temperature range is -55°C to 105°C.
The contact finish is Tin-Lead with a thickness of 30.0µin (0.76µm).
