| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,875 pcs
|
2875 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
2,502 pcs
|
2502 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Approval Agency | |
| Automotive Grade | |
| Breaking Capacity @ Rated Voltage | |
| Climatic Category | |
| Current Rating (Amps) | |
| Fuse Type | |
| Height | |
| Housing Material | |
| Industrial Grade | |
| Length | |
| Melting I²t | |
| Mounting Type | |
| Operating Temperature | |
| Package / Case | |
| Response Time | |
| Soldering Method | |
| Storage Temperature | |
| Tape & Reel | |
| Terminal Material | |
| Termination Style | |
| Voltage Rating | |
| Weight | |
| Width |
The Schurter 3403.0286.23 is a board mount fuse rated for 16A at 250V with a slow blow response time. Designed for surface mount applications, it comes in a compact 2-SMD square end block package measuring 15.40mm x 5.35mm x 5.35mm. This fuse features a ceramic housing with Ni/Sn-plated copper alloy terminals and is rated for an operating temperature range of -55°C to 125°C. It carries approvals from CQC, cURus, and VDE, and is MSL 1 compliant with an unlimited moisture sensitivity level. The melting I²t is 640 A²s, and it has a breaking capacity of 500A at rated voltage. Suitable for primary protection on SMD PCBs, this fuse can be used in power supplies, sensors, and battery protection circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.93 | $3.93 |
| 5+ | $3.26 | $3.26 |
| 10+ | $3.01 | $3.01 |
| 50+ | $2.50 | $2.50 |
| 100+ | $2.30 | $2.30 |
| 250+ | $2.07 | $2.07 |
| 500+ | $1.91 | $1.91 |
| 1,500+ | $1.67 | $1.67 |
| 3,000+ | $1.54 | $1.54 |
| 4,500+ | $1.48 | $1.48 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
16 A
250 V
500 A
Slow Blow
2-SMD, Square End Block
-55°C to 125°C
CQC, cURus, VDE
