| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adjustment Type | |
| Insulation Resistance | |
| Lead Style | |
| Mounting Type | |
| Number of Turns | |
| Power (Watts) | |
| Resistance | |
| Resistive Material | |
| Resolution | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Temperature Range | |
| Termination Style | |
| Tolerance | |
| Torque | |
| Weight |
The Bourns 3386T-1-501LF is a 3/8" square trimming potentiometer from the Trimpot series. It offers a resistance value of 500 Ohms with a standard tolerance of ±10% and a power rating of 0.5 watts at 85°C. This cermet potentiometer features infinite resolution and a top adjustment type.
Designed for industrial applications, the 3386T-1-501LF operates within a temperature range of -55°C to +125°C and has a temperature coefficient of ±100ppm/°C. It is sealed for environmental protection and meets stringent humidity, vibration, and shock test standards. The unit is available with PC pins for through-hole mounting.
Key electrical characteristics include an insulation resistance of 1,000 megohms minimum at 500 VDC and a dielectric strength of 900 VAC at sea level. The mechanical specifications include a 280° nominal adjustment angle, a maximum torque of 5.0 oz-in, and a stop strength of 15.0 oz-in minimum. The physical dimensions are 0.375" x 0.375" face.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 500 Ohms.
The power rating is 0.5W, or 1/2W.
The temperature coefficient is ±100ppm/°C.
It features top adjustment.
It is designed for through-hole mounting.
The standard packaging is 50 pieces per tube.
