| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,650 pcs
|
1650 pcs | On Request | 1 | On Request | On Request | 16+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adjustment Type | |
| Insulation Resistance | |
| Lead Spacing | |
| Mounting Type | |
| Number of Turns | |
| Power (Watts) | |
| Resistance | |
| Resistive Material | |
| Resolution | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Temperature Range | |
| Termination Style | |
| Tolerance | |
| Torque | |
| Weight |
The Bourns 3386P-1-201LF is a single-turn, sealed, cermet trimming potentiometer designed for industrial applications. It offers a resistance value of 200 Ohms with a standard tolerance of ±10% and a power rating of 0.5W at 85°C.
This trimmer potentiometer features a top adjustment type and PC pin termination, making it suitable for through-hole mounting. The device operates within a wide temperature range of -55°C to +125°C and has a temperature coefficient of ±100 PPM/°C. Its sealed construction ensures reliability in various environmental conditions.
The physical dimensions are a square 0.375" x 0.375" face (9.53mm x 9.53mm). The 3386P-1-201LF is part of the Trimpot® 3386 series, known for its robust performance and versatility in trimmer applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Bourns 3386P-1-201LF has a resistance of 200 Ohms.
The power rating is 0.5W at 85°C.
The resistance tolerance is ±10%.
The temperature coefficient is ±100 PPM/°C.
It is a through-hole mounted component with PC pin termination.
The operating temperature range is -55°C to +125°C.
The resistive material is Cermet.
