| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
12,500 pcs
|
12500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Pitch | |
| Row Spacing | |
| Style | |
| Termination | |
| Voltage Rating |
The TE Connectivity 338070-4 is a 4-position receptacle connector part of the Micro-MaTch series. It features two rows of tin-plated forked contacts with a 2.54mm pitch and 2.54mm row spacing.
It is designed for through hole right angle mounting with kinked pin solder termination. The connector uses a friction lock fastening mechanism for secure mating. The red insulation housing is made with a UL94 V-0 flammability rated material.
This connector is suitable for board-to-board or cable interconnections. It is rated for 100VDC operation and can operate over a temperature range of -40°C to 105°C. The contact length is 3.10mm and insulation height is 5.80mm.
The Micro-MaTch contact design incorporates an additional positioning spring to prevent fretting corrosion, ensuring reliable connections in vibration-prone applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.11 | $1.11 |
| 10+ | $0.95 | $0.95 |
| 100+ | $0.80 | $0.80 |
| 500+ | $0.72 | $0.72 |
| 1,000+ | $0.68 | $0.68 |
| 2,500+ | $0.64 | $0.64 |
| 5,000+ | $0.61 | $0.61 |
| 7,500+ | $0.59 | $0.59 |
| 12,500+ | $0.57 | $0.57 |
| 17,500+ | $0.56 | $0.56 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions
2.54mm (0.100 inches)
100VDC
Through hole, right angle
Tin
Red
-40°C to 105°C
