| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,900 pcs
|
2900 pcs | On Request | 1 | On Request | On Request | 11+ | On Request | On Request | |
|
621 pcs
|
621 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adjustment Type | |
| Insulation Resistance | |
| Lead Style | |
| Mounting Type | |
| Number of Turns | |
| Power (Watts) | |
| Resistance | |
| Resistive Material | |
| Resolution | |
| Temperature Coefficient | |
| Temperature Range | |
| Termination Style | |
| Tolerance |
The Bourns 3362P-1-202LF is a single-turn, cermet trimming potentiometer designed for industrial applications. It offers a standard resistance range from 10 ohms to 2 megohms, with this specific unit rated at 2 kΩ.
Key electrical characteristics include a resistance tolerance of ±10% and a power rating of 0.50W at 70°C. The temperature coefficient is ±100 PPM/°C, ensuring stable performance across a wide operating temperature range of -55°C to +125°C.
This trimmer potentiometer features a top adjustment and PC pin termination style, suitable for through-hole mounting. Its sealed construction withstands harsh environments and immersion cleaning processes. The miniature package size is approximately 0.275" x 0.260" (6.99mm x 6.60mm).
Environmental testing includes humidity resistance per MIL-STD-202 Method 103, vibration resistance up to 30G, and shock resistance up to 100G. Load life testing is rated for 1,000 hours at 0.5W @ 70°C, and rotational life is rated for 200 cycles.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Bourns 3362P-1-202LF trimmer potentiometer has a resistance of 2 kOhms.
The power rating is 0.50W at 70°C.
The temperature coefficient is ±100 PPM/°C.
It is designed for through-hole mounting.
The resistive material is Cermet.
