| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
35 pcs
|
35 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Cable Exit | |
| Cable Type | |
| Color | |
| D-Sub Shell Size | |
| Features | |
| Flammability Rating | |
| Hardware | |
| Material | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature Range | |
| Plating | |
| Shielding | |
| Termination Style | |
| cable_diameter (Minimum/Maximum) |
The 3M 3357-6525-1C is a two-piece D-Sub backshell from the 3357 series, designed to house 25-position D-Sub connectors. It features a 45° cable exit angle, accommodating round cable diameters from 5.84 mm to 11.43 mm (for 25-position shells). The housing is constructed from ABS plastic with nickel over copper plating, providing shielding against EMI and ESD. The backshell assembly includes jackscrews (4-40) for positive retention and a compression insert for strain relief. It has a UL 94V-0 flammability rating and an operating temperature range of 0°C to +75°C. Termination is via IDC, and the backshell is intended for free hanging (in-line) mounting. This backshell is part of 3M's metallised plastic D-Sub backshell family, offering a lightweight yet robust solution for protecting D-Sub connector terminations in cable assemblies.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.65 | $6.65 |
| 10+ | $5.65 | $5.65 |
| 25+ | $5.30 | $5.30 |
| 50+ | $5.04 | $5.04 |
| 100+ | $4.80 | $4.80 |
| 300+ | $4.45 | $4.45 |
| 500+ | $4.29 | $4.29 |
| 1,000+ | $4.08 | $4.08 |
| 2,500+ | $3.83 | $3.83 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This backshell supports 25 positions.
The cable exit angle is 45°.
Yes, it is shielded with nickel over copper plating on an ABS housing.
The operating temperature range is 0°C to +75°C.
The housing has a UL 94V-0 flammability rating.
The mounting type is free hanging (in-line).
This backshell is compatible with D-Sub shell size B.
