3296X-1-104LF
Bourns
The Bourns 3296X-1-104LF is a 100 kΩ trimmer potentiometer with a 0.5W power rating and ±10% tolerance. It features a Cermet resistive material and PC pin termination style.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,329 pcs
|
1329 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adjustment Type | |
| Insulation Resistance | |
| Lead Style | |
| Mounting Type | |
| Number of Turns | |
| Power (Watts) | |
| Resistance | |
| Resistive Material | |
| Resolution | |
| Temperature Coefficient | |
| Temperature Range | |
| Termination Style | |
| Tolerance | |
| Torque |
The Bourns 3299P-1-104 is a 3/8" square, multiturn trimmer potentiometer designed for industrial applications. It features a Cermet resistive element with a resistance value of 100 kΩ and a standard tolerance of ±10%. The potentiometer is rated for 0.5W power at 70°C and has a wide operating temperature range of -55°C to +125°C.
This model offers infinite resolution and a side adjustment type for precise control. The termination style is PC pins, suitable for through-hole mounting. The physical dimensions are rectangular, measuring 0.240" x 0.375" face (6.10mm x 9.53mm). The Bourns 3299P-1-104 is built for reliability, with specifications including a 25-turn effective travel and a torque of 3.0 oz-in maximum.
Environmental testing includes humidity resistance per MIL-STD-202 Method 103 and vibration resistance up to 20 G. Load life testing is rated for 1,000 hours at 0.5W @ 70°C. The unit is sealed and designed to withstand industrial processing conditions.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Bourns 3299P-1-104 has a resistance value of 100 kΩ.
The power rating is 0.5W at 70°C.
The temperature coefficient is ±100 ppm/°C.
It supports through-hole mounting.
The standard package is 50 pieces per tube.
