| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| BEC Max Current | |
| BEC Voltage | |
| Control | |
| Current | |
| Interface | |
| Motor Type | |
| Mounting Type | |
| Number of Motors | |
| Peak Output Current | |
| Type | |
| Voltage |
The Pololu 3284, also known as the RoboClaw 2x7A (V5C), is a dual-channel motor controller for brushed DC motors. It provides a continuous output current of 7.5A per channel, with a peak current of 15A, and supports operating voltages from 6V to 34V.
This motor controller features integrated dual quadrature decoders for closed-loop speed control systems. It can be controlled via USB serial, TTL serial, RC, or analog inputs, offering versatile integration options for embedded systems and robotics projects. The RoboClaw supports 3.3V or 5V logic levels and includes features like travel limit switches, home switches, and emergency stop inputs.
A built-in switching mode BEC supplies 5VDC at up to 1.2A for powering auxiliary devices. The RoboClaw 2x7A (V5C) is designed for chassis mounting and is suitable for applications requiring precise control of two brushed DC motors.
This specific version (V5C) has been discontinued and replaced by the RoboClaw 2x7A (V6B), which serves as a drop-in replacement in most applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The RoboClaw 2x7A (V5C) provides a continuous output current of 7.5A per channel.
The RoboClaw 2x7A (V5C) operates up to a maximum voltage of 34V.
The RoboClaw 2x7A (V5C) is designed to control two brushed DC motors.
The RoboClaw 2x7A (V5C) supports USB serial, TTL serial, RC, and analog inputs.
Yes, it features a built-in switching mode BEC that supplies 5VDC at up to 1.2A.
The RoboClaw 2x7A (V5C) is a chassis mount type.
