| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Ambient Temperature (Operation) | |
| Ambient Temperature (Storage/Transport) | |
| Color | |
| Current | |
| Degree of Pollution | |
| Features | |
| Flammability Rating | |
| Height | |
| Housing Color | |
| Insulating Material | |
| Insulating Material Group | |
| Lead Style | |
| Maximum Load Current | |
| Maximum Total Current | |
| Maximum power dissipation | |
| Minimum Order Quantity | |
| Mounting Type | |
| Nominal Current | |
| Nominal Voltage | |
| Number of Levels | |
| Number of Positions | |
| Overvoltage Category | |
| Packing Unit | |
| Rated Surge Voltage | |
| Terminal | |
| Termination Style | |
| Type | |
| Voltage | |
| Weight per Piece | |
| Width | |
| Wire Cross Section | |
| Wire Gauge or Range |
This Phoenix Contact 3273458 distribution block offers 18 positions in a single level with push-in connection technology for tool-free wiring. Rated at 24A nominal current (maximum load 32A, total 48A) and 450V nominal voltage, it accepts wire cross sections from 0.14 to 4 mm² (AWG 26-12). The block is black/yellow with an insulating material of PA, flammability rated UL 94 V0. It supports adhesive, DIN rail, or direct mounting. Key technical parameters include rated surge voltage 6 kV, pollution degree 3, overvoltage category III, insulating material group I, and maximum power dissipation 0.77 W per connection block. Operating temperature ranges from -35 to 85°C, storage from 4 to 38°C. The block allows transverse mounting for space savings on DIN rail and can be bridged via the conductor shaft. Packing unit is 8 pieces with a minimum order of 8. Country of origin is Poland. Made to order (non-returnable).
It has 18 positions (connections) on one level.
The nominal voltage is 450 V.
Nominal current is 24 A, with maximum load current 32 A and maximum total current 48 A.
Primary mounting is adhesive; also supports DIN rail and direct mounting.
Wire cross section 0.14 to 4 mm², equivalent to AWG 26 to 12.
Operating temperature is -35 to 85 °C.
Yes, the insulating material has a flammability rating of UL 94 V0.
