| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
97 pcs
|
97 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adjustment Type | |
| Insulation Resistance | |
| Lead Spacing | |
| Mounting Type | |
| Number of Turns | |
| Power (Watts) | |
| Resistance | |
| Resistive Material | |
| Resolution | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Temperature Range | |
| Termination Style | |
| Tolerance | |
| Torque | |
| Weight |
The Bourns 3266P-1-202 is a 1/4W square trimming potentiometer from the Trimpot® 3266 series. It offers a standard resistance range from 10 ohms to 1 megohm, with this specific unit rated at 2 kOhms and a tolerance of ±10%.
This cermet potentiometer features infinite resolution and a temperature coefficient of ±100 PPM/°C. It is designed for industrial and sealed applications, with standoffs that allow for thorough PC board washing. The effective travel is 12 turns nominal, and it has a side adjustment type.
Environmental characteristics include a wide operating temperature range of -55 °C to +125 °C. It has undergone seal tests at 85 °C and meets humidity, vibration, and shock standards. The unit is built with solderable pins for termination and is suitable for through-hole mounting.
Physical characteristics include a maximum torque of 3.0 oz-in. The standard packaging is 50 pieces per tube, and tape and reel packaging is also available. This model is RoHS compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Bourns 3266P-1-202 trimmer potentiometer has a resistance of 2 kOhms.
The power rating for the 3266P-1-202 trimmer potentiometer is 0.25W at 70°C.
The tolerance for the Bourns 3266P-1-202 trimmer potentiometer is ±10%.
The temperature coefficient of the 3266P-1-202 trimmer potentiometer is ±100 PPM/°C.
The 3266P-1-202 trimmer potentiometer has 12 turns.
The 3266P-1-202 trimmer potentiometer features side adjustment.
The Bourns 3266P-1-202 trimmer potentiometer has a through-hole mounting type.
