3224W-1-503E The Bourns 3224W-1-503E is a cermet trimmer potentiometer featuring 50 kΩ resistance and a ±10% tolerance. It is designed for surface mount applications.
Mfr Part #:

3224W-1-503E

Available from 8 distributors
Mfr Name: Bourns
Bourns
The Bourns 3224W-1-503E is a cermet trimmer potentiometer featuring 50 kΩ resistance and a ±10% tolerance. It is designed for surface mount applications.
✓ Total Stock: 3,692 pcs
$ Price Range: $0.05

3224W-1-503E Available from 8 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

3224W-1-503E Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Adjustment Type
Lead Style
Mounting Type
Number of Turns
Power (Watts)
Resistance
Resistive Material
Storage Temperature
Tape & Reel
Temperature Coefficient
Termination Style
Tolerance
View Similar Products (0)

3224W-1-503E Description

Short technical summary and product information.

The Bourns 3224W-1-503E is a surface mount trimmer potentiometer with a resistance value of 50 kΩ and a tolerance of ±10%. It offers a power rating of 0.25W and a temperature coefficient of ±100ppm/°C.



This component features a J lead termination style and a top adjustment for ease of use. The resistive material is cermet, providing reliable performance. The package size is rectangular, measuring 0.189" x 0.138" face (4.80mm x 3.50mm).



Designed for applications requiring precise resistance adjustments, the 3224W-1-503E is suitable for various electronic circuits where space is a consideration due to its surface mount form factor.

3224W-1-503E Quick Information

Product Type: Trimmer Potentiometer
Canonical Name: Bourns 3224W-1-503E Cermet Trimmer Potentiometer
Subcategory: Trimmer

3224W-1-503E Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

3224W-1-503E Estimated Pricing

Qty Low High
1+ $0.05 $0.05

Estimated market price range - modelled values for guidance only, not live distributor offers.

3224W-1-503E Features

  • 50 kΩ resistance with ±10% tolerance.
  • 0.25W power rating for reliable operation.
  • Cermet resistive material for stability.
  • Surface mount with J lead termination.
  • Top adjustment for easy setting.

3224W-1-503E Applications

  • Ideal for circuit calibration needs.
  • Suitable for compact electronic designs.
  • Used in automated assembly processes.
  • Provides precise resistance adjustment.

3224W-1-503E FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance of the 3224W-1-503E potentiometer?

The resistance of the 3224W-1-503E potentiometer is 50 kΩ.

What is the tolerance of the 3224W-1-503E trimmer potentiometer?

The tolerance of the 3224W-1-503E trimmer potentiometer is ±10%.

What is the power rating for the 3224W-1-503E?

The power rating for the 3224W-1-503E is 0.25W.

What is the temperature coefficient of the 3224W-1-503E?

The temperature coefficient of the 3224W-1-503E is ±100ppm/°C.

How is the 3224W-1-503E mounted?

The 3224W-1-503E is a surface mount component.

What is the termination style of the 3224W-1-503E?

The termination style of the 3224W-1-503E is J Lead.
