3224W-1-205E The Bourns 3224W-1-205E is a cermet trimmer potentiometer with 2 MOhms resistance and a 0.25W power rating. It features a J Lead surface mount termination and 12 turns for precise adjustment.
Mfr Part #:

3224W-1-205E

Available from 1 distributors
Mfr Name: Bourns
Bourns
The Bourns 3224W-1-205E is a cermet trimmer potentiometer with 2 MOhms resistance and a 0.25W power rating. It features a J Lead surface mount termination and 12 turns for precise adjustment.
✓ Total Stock: 6,777 pcs
$ Price Range: $0.05

3224W-1-205E Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
6,777 pcs
On Request
6777 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

3224W-1-205E Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Adjustment Type
Lead Style
Mounting Type
Number of Turns
Power (Watts)
Power Rating
Resistance
Resistive Material
Temperature Coefficient
Termination Style
Tolerance
View Similar Products (0)

3224W-1-205E Description

Short technical summary and product information.

This Bourns 3224W-1-205E is a cermet trimmer potentiometer designed for surface mount applications. It offers a resistance value of 2 MOhms with a tolerance of ±10% and a power rating of 0.25W (1/4W).



The potentiometer features a J Lead termination style and a top adjustment mechanism with 12 turns, allowing for fine-tuning of resistance. Its compact rectangular size of 0.189" x 0.138" (4.80mm x 3.50mm) makes it suitable for space-constrained designs.



With a temperature coefficient of ±100ppm/°C, this component is suitable for various electronic circuits requiring stable resistance adjustments. The RoHS3 compliant status indicates adherence to environmental regulations.

3224W-1-205E Quick Information

Product Type: Trimmer Potentiometer
Series: 3224
Canonical Name: Bourns 3224W-1-205E Cermet Trimmer Potentiometer
Subcategory: Trimmer Potentiometer

3224W-1-205E Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

3224W-1-205E Estimated Pricing

Qty Low High
1+ $0.05 $0.05

Estimated market price range - modelled values for guidance only, not live distributor offers.

3224W-1-205E Features

  • 2 MOhms resistance with ±10% tolerance.
  • 0.25W power rating for general use.
  • 12 turns for precise adjustment.
  • Cermet resistive material for stability.
  • Surface mount with J Lead termination.

3224W-1-205E Applications

  • Ideal for circuit calibration needs.
  • Suitable for compact electronic designs.
  • Used in adjustable voltage dividers.
  • Applicable in signal conditioning circuits.

3224W-1-205E FAQs

7 frequently asked questions generated from this part’s specifications.
What is the resistance value of the 3224W-1-205E trimmer potentiometer?

The resistance value is 2 MOhms.

What is the power rating of this Bourns trimmer potentiometer?

The power rating is 0.25W, or 1/4W.

What is the tolerance for the 3224W-1-205E?

The tolerance is ±10%.

How many turns does the adjustment mechanism have?

The adjustment mechanism has 12 turns.

What type of material is used for the resistive element?

The resistive material is Cermet.

What are the dimensions of the trimmer potentiometer?

The size is Rectangular - 0.189" x 0.138" Face (4.80mm x 3.50mm).

Is the 3224W-1-205E RoHS compliant?

Yes, it is RoHS3 Compliant.
