3224W-1-202E The Bourns 3224W-1-202E is a cermet trimmer potentiometer with 2kΩ resistance and a 0.25W power rating. It features a surface mount J lead termination and top adjustment.
Mfr Part #:

3224W-1-202E

Available from 8 distributors
Mfr Name: Bourns
Bourns
The Bourns 3224W-1-202E is a cermet trimmer potentiometer with 2kΩ resistance and a 0.25W power rating. It features a surface mount J lead termination and top adjustment.
✓ Total Stock: 1,477 pcs
$ Price Range: $0.05

3224W-1-202E Available from 8 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

3224W-1-202E Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Adjustment Type
Lead Style
Mounting Type
Number of Turns
Power (Watts)
Resistance
Resistive Material
Storage Temperature
Tape & Reel
Temperature Coefficient
Termination Style
Tolerance
View Similar Products (0)

3224W-1-202E Description

Short technical summary and product information.

The Bourns 3224W-1-202E is a cermet trimmer potentiometer designed for precise resistance adjustments. It offers a resistance value of 2 kΩ with a tolerance of ±10% and a power rating of 0.25W (1/4W).



This trimmer potentiometer features 12 turns for fine adjustment and a temperature coefficient of ±100ppm/°C. The size is rectangular, measuring 0.189" x 0.138" face (4.80mm x 3.50mm). It is designed for surface mounting with a J lead termination style and top adjustment.



Key electrical and mechanical specifications make the 3224W-1-202E suitable for various electronic circuits requiring adjustable resistance. Its robust cermet resistive material ensures reliability and stability in operation.

3224W-1-202E Quick Information

Product Type: Trimmer Potentiometer
Canonical Name: Bourns 3224W-1-202E Cermet Trimmer Potentiometer

3224W-1-202E Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

3224W-1-202E Estimated Pricing

Qty Low High
1+ $0.05 $0.05

Estimated market price range - modelled values for guidance only, not live distributor offers.

3224W-1-202E Features

  • 2kΩ resistance with ±10% tolerance.
  • 0.25W power rating.
  • 12 turns for precise adjustment.
  • Cermet resistive material.
  • Surface mount J lead termination.

3224W-1-202E Applications

  • Ideal for adjustable voltage dividers.
  • Used in calibration circuits.
  • Suitable for power supply adjustments.
  • Applicable in test and measurement equipment.

3224W-1-202E FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the Bourns 3224W-1-202E?

The resistance value is 2 kΩ.

What is the power rating of this trimmer potentiometer?

The power rating is 0.25W, or 1/4W.

What is the tolerance for the Bourns 3224W-1-202E?

The tolerance is ±10%.

How many turns does the 3224W-1-202E have?

It has 12 turns.

What type of mounting is required for the 3224W-1-202E?

It requires surface mounting.

What is the termination style of this Bourns trimmer potentiometer?

The termination style is J Lead.
