| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Conductor Cross Section (Solid) | |
| Conductor Cross Section (Stranded) | |
| Conductor Cross-Section (AWG) | |
| Connection Type | |
| Current | |
| Current (Rated) | |
| Flammability Class | |
| Height (NS 35/15) | |
| Height (NS 35/7.5) | |
| Industrial Grade | |
| Insulating Material | |
| Insulating Material Group | |
| Lead Style | |
| Length | |
| Maximum Load Current | |
| Mounting Type | |
| Nominal Current IN | |
| Nominal Voltage UN | |
| Number of Levels | |
| Number of Positions | |
| Pollution Degree | |
| Rated Surge Voltage | |
| Standard Package Qty | |
| Surge Voltage Category | |
| Terminal | |
| Terminal Width | |
| Termination Style | |
| Type | |
| Voltage | |
| Voltage - Rated | |
| Wire Gauge or Range | |
| Wire Insulation Material |
The Phoenix Contact QTC 1,5-TWIN BU (3205051) is a feed through modular terminal block designed for DIN rail mounting. It provides 3 connections in a single level, with a compact width of 5.2 mm. The terminal block utilizes a quick connection method for solid or stranded conductors, supporting cross sections from 0.25 mm² to 1.5 mm² (24 to 16 AWG).
The electrical ratings include a nominal current of 17.5 A and a nominal voltage of 800 V, with a rated surge voltage of 8 kV and pollution degree 3. The insulating material is polyamide (PA) with a flammability class of V0 per UL 94. The block is RoHS3 compliant and has been WEEE/RoHS-compliant since 2003.
Mounting is on NS 35/7.5 or NS 35/15 DIN rails, with dimensions of 76.4 mm length and heights of 39.3 mm (NS 35/7.5) or 46.8 mm (NS 35/15). The standard packaging contains 50 pieces.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.91 | $2.91 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 3 positions (connections) in a single level.
The nominal current is 17.5 A, with a maximum load current of 17.5 A (with 1.5 mm² conductor cross section).
The nominal voltage is 800 V, and the rated voltage is 600 V.
It mounts on NS 35/7.5 or NS 35/15 DIN rails.
It accepts solid or stranded conductors from 0.25 mm² to 1.5 mm² (24 to 16 AWG).
The connection type is quick connection (IDC per some sources, but datasheet specifies quick connection).
The insulating material is polyamide (PA) with a flammability class of V0 per UL 94.
