| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Contact Resistance | |
| For Use With | |
| Insulation Resistance | |
| Mounting Type | |
| Panel Thickness | |
| Storage Conditions | |
| Terminal | |
| Terminal Style |
The Schurter Inc. 3101.7021 is a shock-safe fuseholder compatible with 5x20 mm fuse links. It features a compact design with screw-on mounting from the front side and a fixing nut attachment. The terminals support both solder and 4.8 x 0.5 mm quick-connect connections.
This fuseholder is rated for 250 VAC (VDE) or 500 V (UL/CSA) and can handle a rated current of 10 A (VDE) or 16 A (UL/CSA). It offers a degree of protection of IP40 or IP67, making it suitable for various environmental conditions. The operating temperature range is -40 °C to 85 °C.
Constructed with a black thermoplastic socket (UL 94V-0) and tin-plated copper alloy terminals, the 3101.7021 is designed for durability. It is suitable for appliances with protection class I according to IEC 61140. The fuseholder has a unit weight of 5.7 g and supports panel thicknesses up to 6 mm.
The operating temperature range is -40°C to +85°C.
The voltage rating is 250VAC under VDE and 500V under UL/CSA.
The current rating is 10A under VDE and 16A under UL/CSA.
The ingress protection rating is IP40 / IP67.
It accepts 5x20mm fuse links.
It is panel mount, front side, secured with a fixing nut.
Terminals are solder or quick-connect 4.8x0.5mm.
